| M3BA SERIES |
| |
| ABB is a leader in power and automation technologies that enable utility and
industry customers to improve their performance while lowering environmental
impact. The ABB Group of companies operates in around 100 countries and
employs about 110,000 people. |
| |
| Cast Iron Motors 71 to 132
according to Indian standards |
| |
| The new generation of cast iron motors is based on
the new product design, which has been developed
in response to market demands and is based on customer feedback. They fulfill the requirements of
Indian standard IS 12615 *Energy Efficient Induction
Motors - Three Phase Squirel Cage*. |
| |
|
| |
|
 |
|
| M2BA SERIES |
| |
| The 'M2000' Series |
| M2000 Motors have been engineered for the twin objective of high power
0 to weight ratio and efficiency at a designed ambient of 50 C. The
performance of 'M2BA' is well ahead of relevant IEC & IS standards
resulting in lower energy consumption, reduced operational costs and
ultimately faster returns on investment. 'M2BA' Motors have a wide range
of applications including windmill. |
| |
|
| |
| |
| |
|
|
|
| HX+ SERIES |
| |
| The most widely used motors from the world leaders |
- TEFC, S1 Duty
- 415 ± 10% V, 50Hz ± 5%.
- Combined Variation of (absolute sum 10%)
- Insulation Class F
- 0 Temperature rise Class B ( 70 C)
|
|
| |
|
|
|
| FLAME PROOF SERIES |
| |
| Feature |
| |
| The use of electrical motors in potentially explosive atmospheres is quite
frequuent these days. These motors have to be constructed in such a way that
there is no risk of an explosion. An Explosion occurs when the following
situatuions occur: |
| |
- presence of potentially explosive atmosphere
- existence of a source of ignition
- possibility of transmission of the explosion
|
|
| |
|
|
|
|
|
|
