  Etanorm SYT

 Thermal Oil / Hot Water Pumps

  Feature
  • Maximum Operating Reliability
  • High energy efficiency
  • Easy to service
  • Robust Design
  Applications
  • Heat transfer system ( DIN 4754, VDI 3033 )
  • Hot water circulation ( DIN 4752 )

Technical Data * Etanorm SYT / RSY
  Thermal Oil Hot Water
 Max. Flow Rate 1900 / 2280 1900 / 2280 m3/h
 Max. Head 102 / 90 102 / 90 m
 Fluid Temperature -30 to +350 up to +180 °C
 Max. Operating Pressure 16 16 bar
 * Values for 50 Hz/60 Hz

   Automation Options :  PumpDrive, PumpExpert, Hyamaster, Hyatronic

MEGA Pumps
  MEGA

  Feature
  • Flanges as per ASME (formerly ANSI) B 16.1 Class 125
  • Modular construction, high interchangeability, fast delivery
  • Versatile shaft sealing arrangement, Gland packing as a standard arrangement and option to use mechanical
  Operating data
  • Design : Horizontal back pull-out
  • Pump size : DN 32 to 150 mm
  • Capacity : up to 540 m3/hr
  • Head : up to 100 m
  • Discharge pr. : up to 16 bar
  • Temperature : -30°C to +160°C
  • Material : C. I., C. I. with Bronze internals,C.I. with S. S. internals
  Application
  • Water supply
  • Drip irrigation
  • Cooling water circulation
  • Industrial washing machines
  • Condensate handling
MEGA Pumps
  MEGA CHEM

  Feature
  • Flanges as per ASME B 16.5 Class 150 ( Drilling only )
  • Modular construction, high interchangeability, fast delivery
  • Versatile shaft sealing arrangement, Gland packing as a
  • standard arrangement and option to use mechanical seal
  • Process type design results in minimum downtime
  Operating data
  • Design : Horizontal back pull-out
  • Pump size : DN 32 to 125 mm
  • Capacity : up to 400 m3/hr
  • Head : up to 100 m
  • Discharge Pr. : up to 24 bar
  • Temperature : -30°C to +200°C
  • Material : Cast Steel with various combinations in S. S., C. S.
  Application
  • Water treatment
  • Organic & inorganic liquids
  • Reverse osmosis
  • Handling of pulp
  • Solvent extraction
  • Condensate handling

MEGA CHAN Pumps
 cpk

  Feature
  • Versatile due to broad range of materials
  • Constant-level oiler
  • Maintenance-friendly
  • Long service life
  • Low operating costs
  Operating data
  • Design : End suction process pump
  • Pump size : DN 32 to 250 mm
  • Capacity : up to 1200 m3/hr
  • Head : up to 150 m
  • Discharge Pr. : up to 25 bar
  • Temperature : -70°C to +320°C
  • Material : C. I., S. S., C. S., Cr. S.
  Application
  • Paper industry
  • Organic/inorganic fluids
  • Handling of sea water
  • Sugar industry
  • Food processing industry
  • Petrochemical industry
  • Chemical industry

CPK Pumps
  MegaCPK

  Standardised Chemical Pump

  Feature
  • In compliance with relevant standards
  • High reliability and lower operating costs
  • Energy Efficiency
  • Lower investment costs
  • Large range of variants for all applications
  • The right size for each application
  • Easy to Service
  Applications
  For handling aggressive organic and inorganic fluids in
  • Chemical Industry
  • Petrochemical Industry
  • Process Engineering
  • Sugar Industry
  • Biodiesel, bioethanol
  • Fire-fighting systems / fire-fighting water
  • Seawater desalination / reverse osmosis
  • Condensate
  • Hot Water
  • Brine
  • Steel Industry
  • Heat Transfer Media
  • Cleaning Agents

Technical Data *
 Flow Rate Q Up to 1160 m3 / h ( 50 Hz )
Up to 1400 m3 / h ( 60 Hz )
 Head H Up to 162 m ( 50 Hz )
Up to 233 m ( 60 Hz )
 Operating Temperature t -40 °C to +400 °C
 Operating Pressure p Up to 25 bar

MEGA Pumps
 KWP

  Feature
  • Flanges to DIN 2535/16, 2532/10
  • Interchangeable wear plate in various materials
  • Two type of impellers for vide range of applications
  • Axially adjusted bearing bracket with option of heavy
    bearing bracket
  Operating data
  • Design : End suction non-clog pump
  • Pump size : DN 65 to 200 mm
  • Capacity : up to 700 m3/hr
  • Head : up to 100 m
  • Discharge Pr. : up to 10 bar
  • Temperature : -30°C to +250°C
  • Material : C. I. with C.S. internals, C. S.
  Application
  • Sugar industry
  • Paper industry
  • Sewage & effluent
    treatment plant
  • Chemical industry
  • Handling of foodstuff
  • Mining industry

KWP Pumps
 APP

  Feature
  • Volute casing with low radial forces
  • Externally adjustable wear plate to maintain the clearance between the impeller & wear plate
  • Open impeller for handling of stock up to 8% consistency.
  • Specially designed Spiral key for impeller locking
  Operating data
  • Design : End suction non-clog pump
  • Pump size : DN 50 to 150 mm
  • Capacity : up to 540 m3/hr
  • Head : up to 105 m
  • Discharge Pr. : up to 16 bar
  • Temperature : -100°C to +180°C
  • Material : Cast Iron, S. S. 2324
  Application
  • Handling of paper pulp
  • Process industries
  • Handling of foodstuff

APP Pumps
 WK / WL / WKFI / WKS

  Feature
  • Flanges to DIN standard
  • Normal design for temperature up to 105°C
  • For temperature above 105°C; Hot Water Design with cooled stuffing box is available
  • Axial thrust is balanced by balancing holes on impeller shroud or the balancing and counter balancing disc
  Operating data
  • Design : Multi-stage high pressure pump
  • Pump size : DN 40 to 150 mm
  • Capacity : up to 630 m3/hr
  • Head : up to 780 m
  • Discharge Pr. : up to 63 bar
  • Temperature : -10°C to 230°C
  • Material : C. I., C. I. with Bronze internals C. S., CA6NM
  Application
  • Boiler feed applications
  • Condensate extraction
  • Fire fighting
  • Irrigation
  • Sprinklers

WK / WL / WKFI / WKS Pumps
 movi

  Feature
  • Normal design for temperature up to 110°C
  • Hot water design for temperature from 110°C to 140°C
  • Nozzles can be turned by 90° for easy installations
  • Various combination of impellers for wide performance
  Operating data
  • Design : Multi-stage high pressure pump
  • Pump size : DN 32 mm
  • Capacity : up to 18 m3/hr
  • Head : up to 368 m
  • Discharge Pr. : up to 40 bar
  • Temperature : -10°C to 140°C
  • Material : Cast Iron, C. I. with Bronze internals
  Application
  • General water supply
  • Sprinklers
  • Irrigation
  • Booster plants
  • Fire fighting

MOVI Pumps
 movi tech vcf

  Construction & applications
    Multi-stage, vertical inline high-pressure centrifugal pumps in ring-section design. suitable for general water supply, sprinkling, irrigation and pressure boosting systems, warn water, hot water and colling water re-circulation, boiler feed systems, domestic water supply systems and washing plants.
  Operating data
  • Pump size : DN 25 to 50 mm
  • Capacity : Q up to 24 m/hr.
  • Head : H up to 228 m
  • Discharge pressure : p up to 25 bar
  • Temperature : t -15 ti 120 C
  • Speed : n up to 3600 rpm

MOVI TECHVCF Pumps
 HDA

  Feature
  • Flanges to DIN/ASME/BS
  • Axial thrust balancing by balancing disc
  • Stage sealing by "O" rings
  • Lift off device with segmental thrust bearing enables high no. of start-stops
  • Higher interchangeability
  • Option of cooled stuffing box is available
  Operating data
  • Design : Multi-stage ring-section pump
  • Pump size : DN 40 to 150 mm
  • Capacity : up to 575 m3/hr
  • Head : up to 1750 m
  • Discharge Pr. : up to 230 bar
  • Temperature : up to 230°C
  • Material : C.I., WCB, CA6NM
  Application
  • Handling boiler feed water
  • Descaling plants
  • Coke cutting
  • Pressure generation for
  • hydraulic press
  • Municipal water supply

HDA Pumps
 RPH

  Feature
  • Pump designed to API 610 10th edition
  • Specially designed impeller for low NPSHr
  • Finned bearing bracket with option to use fan for cooling
  • Optional triple bearing assembly for high suction pressure
  • Seal chamber designed to API 682
  Operating data
  • Design : End suction process pump
  • Pump size : DN 25 to 250 mm
  • Capacity : up to 1500 m3/hr
  • Head : up to 270 m
  • Discharge Pr. : up to 51 bar
  • Temperature : up to 450°C
  • Material : Stainless Steel, Chrome Steel
  Application
  • Handling of paper pulp
  • Process industries
  • Handling of foodstuff

RPH Pumps
 krtu / krte

  Feature
  • Stationary & portable executions are available
  • Three types of impeller for handling variety of liquids
  • Safe operation due to resin filled cables gland
  • Bi-directional mechanical seal ensures long service life
  • Temperature sensors protect motor from overheating
  • Can handle solids up to 100 mm diameter
  Operating data
  • Design : Submersible motor pump
  • Pump size : DN 65 and 200 mm
  • Capacity : up to 100 m/hr.
  • Head : up to 100 m
  • Motor power : up to 9.5 kW
  • Temperature : up -30 to 250°C
  • Material : Cast Iron
  Application
  • Water treatment
  • Hotels
  • Water transfer e.g. storm water
  • Food processing industry
  • Paper industry
  • Sugar industry

KRTU/KRTE Pumps
 AMA PORTER

  Feature
  • Vertical monobloc pump set
  • Free flow impeller of 2 sizes
  • Available in 1 & 3 phase supply with IP 68 protection
  • Built-in thermal overload protection, float switch, bi-directional mechanical seal
  Operating data
  • Design : Monobloc pumpset
  • Pump size : DN 50 mm
  • Capacity : up to 29 m3/hr
  • Head : up to 16 m
  • Motor rating : up to 1.5 kW
  • Temperature : up to 40°C
  • Material : C. I.
  Application
  • Pumping of surface water
  • Pumping of rain water
  • Waste water containing solids
  • Drainage of sumps liable to flood

AMA PORTER Pumps
 SubmERsible Motor pumps

  Feature
  • High efficiency
  • Available in radial & mixed flow impeller designs
  • Low power consumption
  • Easily serviceable
  • Environment friendly
  Operating data
  • Design : Submersible Motor Pump
  • Pump size : 150 mm to 350 mm
  • Type series : UQD, BPD, BPH, UPH, BPN, BPVs, BQTs
  • Capacity : up to 900 m3/hr
  • Head : up to 300 m
  • Motor power : up to 110 kW
  Application
  • Agriculture
  • Sprinkler / Drip irrigation
  • Drinking water supply
  • Mine de-watering
  • Commercial complexes
  • Sea water desalination
  • Pressure boosting

Submasible Motors Pumps
 Monosub R

  Construction & applications
    Single stage, monobloc, open-well submersible pumps. suitable for agriculture, drinking water supply, fountains, buildings, farm houses etc. available in single and three phase modles.
  Operating data
  • Pumps size : DN 25 to 100 mm
  • Capacity : Q up to 120 m/hr.
  • Head : H up to 60 m
  • Motor rating : P up to 0.5 to 10 hp






MONOSUB R Pumps
